| Categories | Water Purification Consumables |
|---|---|
| Payment Terms: | Western Union、ESCROW、PayPal、 T/T、L/C |
| Place of Origin: | SiChuan, China |
| Brand Name: | CHUNJIE |
| Certification: | GB/T27922 CE ISO9001 ISO 13485 TUV |
| MOQ: | 1pcs |
| Price: | Negotiable |
| Packaging Details: | Wooden box\carton |
| Delivery Time: | Negotiable |
| Supply Ability: | Very strong |
| Name: | Wire wound filter element |
| Specifications: | 10 inches 5um, 10 inches 10um, etc. |
| Pressure resistance: | 0.5Mpa |
| Inner diameter: | 28±1 mm |
| Outer diameter: | φ58±2mm |
| Features: | Good compatibility |
The wire-wound filter element is made of textile fibers precisely wound on a porous skeleton. The winding scheme of the filter layer and the shape of the filter holes are controlled to produce filter elements with different filtration precisions. It can effectively remove suspended matter, particles, etc. in the liquid; it can withstand higher Filtration pressure; the filter pore size is large on the outside and small on the inside, with excellent deep filtration effect; the filter element has good compatibility; the filter element can be made of a variety of materials to meet the needs of various liquid filtrations.
Wire wound filter is suitable for filtration of tap water, well water, food and beverage water, domestic water, cooling circulating water, boiler water supply, oil field workover fluid and water injection, organic solvents, electroplating fluids, oils, inks, pharmaceutical products, etc. Nominal accuracy and flow rate Note:
1. Filtration efficiency of initial precision N=95%
2. The filtration efficiency of the largest particle is N=99%
3. The accuracy of the filter element gradually increases during circulation filtration.
4. This flow value is the nominal accuracy when filtering water with a 20" standard filter element under the condition of pressure difference P=0.0015Mpa.
| Model | Wire wound filter element |
|---|---|
| Material | Cotton thread |
| Filter element form | Wire wound filter element |
| Purpose | Water filtration |
| Scope of application | Water purifier |
| Applicable objects | Water |
| Type | Initial effect |
| Brand | VOQUAN |
| The main technical parameters | Outer diameter φ58±2mm Inner diameter 28±1 mm Length 500±2mm, pressure resistance 0.5Mpa Temperature 80°C (polypropylene skeleton) 219 Temperature 80° |
| Filtering precision | 5~100 |
| Specifications | 10 inches 5um, 10 inches 10um, 10 inches 20um, 10 inches 50um, 10 inches 100um |
|
