| Categories | SMT Splice Tools |
|---|---|
| Brand Name: | KangHongJin |
| Model Number: | MTL00 |
| Certification: | RoHS |
| Place of Origin: | Guangdong, China |
| Product Name: | MTL00 |
| Material: | Steel Tool body+Plastic Handle |
| High Light: | Splice tools, Tape Splicing Tool, Metal SMT Splice Tool, Tape Splicing Tool, SMT splicing pliers tools |
| DESCRIPTION |
The MTL00 is an ergonomically designed handheld tool used to join carrier tape reels of all widths. |
| Compatible with the M0600 splice clips.The MTL00 is an ergonomically designed handheld tool |
| used to join carrier tape reels of all widths. Compatible with the M0600 splice clips. |
| Part | Dimensions | Material | Weight |
| MTL00 | 21cm x 7cm x 7cm | Steel Tool body+Plastic Handle | 0.5kg |
| APPLICATION | ADVANTAGES |
| 1. Handheld splice tool designed | 1. 5mm placement pin guides for alignment |
specifically for SMT carrier tapes | 2. Clamps to secure carrier tapes |
2. Use with the splice clip (M0600) | 3. Ratchet style crimping tool |
| and splice tapes of any size | 4. Ergonomically designed |
| 3. Ensures carrier tapes of all widths can | |
| be joined securely |
INSTRUCTIONS
1. Crimp the tool handle to open the front panel jaws. |
2. Place a splice clip (teeth up) on the placement pins. |
3. Center both carrier tapes (cover tape up) on the pins, and secure with the clamps. |
4. Crimp the handle to connect the carrier tapes. |
| 5. Add a splice tape strip to the cover tape and press firmly to complete the splice. |
 |
